Quick Details

  • Condition: New
  • CNC or Not: Normal
  • Power Source: Hydraulic
  • Place of Origin: Anhui, China (Mainland)
  • Brand Name: rbqlty
  • Model Number: Q35Y
  • Voltage: 380V/220V Optional
  • Power(W): 15000
  • Weight: 7.2T
  • Dimension(L*W*H): 2680*1100*2300mm
  • Certification: CE ISO
  • Warranty: 2 Years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: shearer and puncher
  • Color: Customizable
  • Keyword: ironworker for hole punching
  • Function: steel punching and shearing cutting
  • Application: Angle Metal Working
  • Usage: Pressing Metal Products
  • Punching press: 160T
  • Material: High Strong Steel
  • Type: Multi-Function Machine
  • Max punching diameter: 38mm

Packaging & Delivery

Packaging Details Plastic film for ironworker for hole punching, or can be according to the requirements of customer
HS code:8462490000
Delivery Time 2 weeks after the deposit received

High speed hydraulic ironworkers for hole punching



Product descriptions:

 1. Robust and accurate steel frame

 2. Large punch table with scales

 3. Removable bolster for punching flanges and channel and beam

 4. 2 independent hydraulic cylinders

 5. 2 shielded foot controls

 6. 2 Separate Die Openings for over sized punching

 7. 5 working stations for wide applications

 8. power inching on all 5 work stations

 9. plate shear support table and notching table

10. adjustable stroke controls with indicators on both cylinders

11. punching machine: Movable work light

12. overload protection on hydraulic system

13. electric back gauge

14. optional bending attachment



Technical data

No.NameNumericalUnitRemarks
1Plate shearA stroke can cut flat steel thickness*width30*335mm
The max size of steel can be cut20*600mm
Blade length610mm
Blade angle8deg
2Cut profilesSquare steel side length65mm
Bar diameter55mm
Channel diameter28mmSpecial orders
I-steel diameter28mmSpecial orders
Equilateral angle of 90°cut180*16mm
3Die cutThickness16mm
Width57mm
Depth100mm
4Punching Thickness28mm
The max diameter38mm
Press force1600kN
Throat depth600mm
Max stroke80mm
Trips6Beats/minFull stroke
5Material strength450N/mm
6Electric motorModelNT4-L160-4
Power15KW
Speed1460r/min
7DimensionsLength2800mm
Width1050mm
Height2450mm



Company Information



About us:

*Expert in kinds of sheet metal processing machines, like bending machine, shearing machine,   iron worker, hydraulic press, punching machine, duct manufacturing auto line, cutting machine and so on

*With an expert team in R&D for more than 20 years, occupied the work shop of over 30,000 square        meters, runbang is able to support you with best quality machines

 *With CE/ISO/SGS certification

FAQ



*We have our own factory and brand; Our machines can match all the CE standard or more strict ones.

*Quality assurance: 2 years warranty and 100% quality inspection before packing.

*Service:Impeccable after-sale service, and all your problem will be solved within 24 hours.

*Price: Can be negotiable according to the qty.

*MOQ:1 set.

*Howtovisit: You can fly to NanJing LuKou airport directly,you can also take high speed train to Nanjing South    Station from other city in China.We will pick you up in the airport or Train station.

Any interest, pls feel free to contact us:



Anhui Runbang Heavy Industry Machinery Co.,Ltd

1.Tel: 0086-553-7567905     Fax:0086-553-5964008

2. Brand: rbqlty

3. Address: Bowang Industrial Park,  Ma’anShan Anhui China

4. Phone(whatsapp): +8613855367553

5. Email: rbsales3(@)rbqlty.com

6. Website:  www.rbqlty.com

7. We chat: 13855367553
